We have 11 designs - 10 for plywood stitch & tape construction and 1 for Cedar strip planking. The
Seawolf plywood design also has an option to be built with a length of
17'6".
|
|
Kayaks on this Page |
||||||||||
| Dart 14 | Dart 16 | Dart 22 | Seawolf | Seafox | Sealion | 12'6" Esk | 14'6" Esk | Greenland 19 | Siton 17 | |
|
Included with each set
of plans - The full canoe catalogue is now on CD in PDF format - this version of the catalogue is packed with colour photographs of our canoe designs (more than on our web pages). The catalogue also has a guide to choosing an open canoe and useful FAQ's pages. The CD also contains a copy of our On-Line Manual which uses 65 colour photographs showing one of our Hazelnut open canoes being built in detail, a copy of a past article on building the Christine Open Trekking Canoe plus an easily printable order form and contact details. Please note that this CD is sent free with each canoe plan and does not need to be ordered separately if ordering a canoe plan from this web site. However, if you do want to order the CD only, go to the Catalogues & Manuals page. (Please note that the cost of the CD is not refundable if you order canoe plans later). Also go to the Catalogues & Manuals page to see details of our new Plywood Canoe Construction Manual which includes details of sail rigs, floats, outboard brackets, seat backs, sponsons, making the canoe in 2 halves etc. |
| We have launched a new site dedicated to canoes and kayaks - go to www.makeacanoe.com where you will find the full range of SFDesign canoes and kayaks plus many more builder's photos of our canoes and sections specifically on strip planked and stitch and tape canoe construction - you can order canoe and kayak plans from this site or the makeacanoe site but you will find a lot more info about our canoes on the new site including a very useful FAQ's page on canoe building (costs, building times etc) and a page on canoe "bits and pieces" - ie. rudders, seats, leeboards, rigs etc. |
| DART 14 | ||||||||||||||||||||||||||||||||||
|
||||||||||||||||||||||||||||||||||
 |
The sporty 14’
single kayak (now in it’s mark 2 version) has a beam of 24’’ and a ‘V’
bottomed soft chine shape giving plenty of stability with a very good tracking
and low wetted surface area hull. Construction uses just 2 1/2 sheets of
Exterior or Marine ply and takes around 25 hours to build.
|
|||||||||||||||||||||||||||||||||
| The above is a nice example by Stuart Moscrop. | ||||||||||||||||||||||||||||||||||
|
||||||||||||||||||||||||||||||||||
|
||||||||||||||||||||||||||||||||||
| Below - an example by Andy White | ||||||||||||||||||||||||||||||||||

|
||||||||||||||||||||||||||||||||||
| Right, an example by
Arthur Smith.
|
|
|||||||||||||||||||||||||||||||||
|
||||||||||||||||||||||||||||||||||
|
DART 14 FULL PLANS COST |
| DART 16 | ||||||||||||||||||||||||||||||||||
|
||||||||||||||||||||||||||||||||||
|
The
Dart 16 double kayak has a soft ‘U’ shaped bottom running into flared ‘V’
sections fore and aft with a chine, giving a very stable shape. She has a large
7’ long cockpit and with her 32’’ (0.81m) beam she is ideal for sea
canoeing. We have had 2 adults and a young boy in the cockpit on a trip around
the Exe and she has plenty of stowage space for camping gear.
Both kayaks have built-in buoyancy chambers fore and aft and in both cases full size shapes are given on the plans for the bulkheads and deck beams. The decks are heavily rounded to give adequate room inside and to easily shed water and the hull panel shapes are easily transferred from the plans to the plywood sheets. The 16 footer will take around 35 hours and uses 3 sheets of ply to build and both canoes are very light and can be carried by one person. |
|||||||||||||||||||||||||||||||||
| The example right is by Robert Chircop. |
|
|||||||||||||||||||||||||||||||||
| Another example under construction - this one by Evan Brown. |
|
|||||||||||||||||||||||||||||||||
|
||||||||||||||||||||||||||||||||||
|
||||||||||||||||||||||||||||||||||
|
||||||||||||||||||||||||||||||||||
|
DART 16 FULL PLANS COST |
| DART 22 | ||||||||||||||||||||||||||||||||||
 |
||||||||||||||||||||||||||||||||||
| The DART 22 uses a similar section to that of the Dart 16. This consists of a tortured ply ‘U’ shape which changes fore and aft into a full ‘V’ giving adequate buoyancy and a good entry at the fore foot. Above the shaped bottom there is a soft chine and flat top sides giving an efficient and handsome shape coupled with ease in construction. As with many of our other designs, the chine stringer is square sectioned and the ‘V’ gap between it and the adjacent topside panel is filled with an epoxy fillet doing away with tedious beveling and speeding up the construction process. The hull has large buoyancy compartments fore and aft and in the centre which can also be used for stowage via watertight hatches. 6 to 7 sheets of 4mm plywood are used in her construction and these may be Exterior grade. Rudder details are also shown on the drawings. | ||||||||||||||||||||||||||||||||||
|
||||||||||||||||||||||||||||||||||
|
DART 22 FULL PLANS COST |
| 16' & 17'6" SEAWOLF | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
 |
Seawolf is a development of the Dart 14 canoe. We have increased her length by 2’ and her width slightly and swept the bow up to make her more suitable for sea use. She has fore and aft buoyancy compartments and a large storage area behind the cockpit entered by a watertight hatch. Construction is by the simple stitch and tape method which keeps weight down to less than 40 lbs (18kg) and she uses 3 sheets of 4mm ply. Details are shown for the self lifting rudder. | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| The above example is by Graham Murphy. | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
16' SEAWOLF FULL PLANS COST |
|
EXTRA FOR 17'6" SEAWOLF PLAN COST |
| 15' 8" SEAFOX | ||||||||||||||||||||||||||||||||||
|
||||||||||||||||||||||||||||||||||
| The Seafox is a development of our Seawolf design using 4 planks per side rather than 2 giving a well rounded and very attractive hull shape. she has storage and buoyancy areas fore and aft and a 3' long cockpit opening. Construction uses 3 sheets of 4mm ply (Exterior or Marine) with the simple stitch and tape process. | ||||||||||||||||||||||||||||||||||
|
||||||||||||||||||||||||||||||||||
|
|
|||||||||||||||||||||||||||||||||
| Below, an example with modified deck by Russell Harley | ||||||||||||||||||||||||||||||||||
|
|
|||||||||||||||||||||||||||||||||
|
||||||||||||||||||||||||||||||||||
|
15' 8" SEAFOX FULL PLANS COST |
| 17' STRIP PLANKED SEALION | ||||||||||||||||||||||||||||||||||
|
|
|||||||||||||||||||||||||||||||||
| The Sealion was originally modelled on our Seafox sea kayak but the use of Cedar Strip planking for her construction allows a more graceful and curvaceous shape both for the hull and the deck. She is built over computer faired mould shapes set up on a strongback (all details and full-sized mould shapes are given on the plans) in 6mm Cedar which is sanded smooth and then sheathed in glass cloth with epoxy resin. | ||||||||||||||||||||||||||||||||||
|
||||||||||||||||||||||||||||||||||
|
17' SEALION FULL PLANS COST |
| 12'6" ESK SEA KAYAK | |||||||||||||||||||||||||||||||||||||||
|
|||||||||||||||||||||||||||||||||||||||
|
The yellow example left is by Bob Day. | ||||||||||||||||||||||||||||||||||||||
|
|||||||||||||||||||||||||||||||||||||||
 |
 |
||||||||||||||||||||||||||||||||||||||
 |
Left is a beautifully built example of the 12' Esk by Dave & Jonny Burke - this one has a strip planked deck - go to their web site at www.up-the-creek.net to see her under construction. | ||||||||||||||||||||||||||||||||||||||
|
Like her bigger sister, the 12’ 6” Esk is a development of our Dart design. She has the swept up bow and flared out forward sections to help her in choppy waters—and we have retained the knife edge to the rear sections to give her good directional stability. She has water-tight
compartments in both ends and space for water-tight stowage. Construction is for
easy stitch and tape ply using 3-4 sheets of 4mm plywood. |
|||||||||||||||||||||||||||||||||||||||
| The finished example below is by Robin Waistell of Albatross boats. | |||||||||||||||||||||||||||||||||||||||
|
|
 |
||||||||||||||||||||||||||||||||||||||
|
|||||||||||||||||||||||||||||||||||||||
|
12' 6" ESK FULL PLANS COST |
| 14'6" ESK SEA KAYAK | ||||||||||||||||||||||||||||||||||||

|
||||||||||||||||||||||||||||||||||||
| The 14’ 6” Esk is a development of our Dart design. We have swept the bow up and flared out the forward sections to help her in choppy waters—aft, we have given her a knife edge to the rear sections to give her good directional stability. She has water-tight compartments in both ends and space for water-tight stowage. Construction is for easy stitch and tape ply using 4 sheets of 4mm plywood. | ||||||||||||||||||||||||||||||||||||
| Right - Richard Smurthwaite in his Esk 14. |
|
|||||||||||||||||||||||||||||||||||
Example left by Adrian Adamson
|
||||||||||||||||||||||||||||||||||||

Example above by Robert Wagenvoort |
||||||||||||||||||||||||||||||||||||
|
Example below by Steve Kirk
|
||||||||||||||||||||||||||||||||||||
| Below - another example by Martin Lunghi with a different shaped cockpit | ||||||||||||||||||||||||||||||||||||
|
|
|||||||||||||||||||||||||||||||||||
| Right, an example by Perttu Korhoren. |
|
|||||||||||||||||||||||||||||||||||
|
||||||||||||||||||||||||||||||||||||
|
14' 6" ESK FULL PLANS COST |
| 17' ESK SEA KAYAK | ||||||||||||||||||||||||||||||||||
 |
||||||||||||||||||||||||||||||||||
|
The 17’ Esk is a
development of our 2 other Esk designs. She has the same swept up bow
and flared out the forward sections to help her in choppy waters and her
additional length gives her more storage space and a good ride in choppy
waters.
She has water-tight compartments in both ends and space for water-tight stowage. Construction is for easy stitch and tape ply using 4 sheets of 4mm plywood. The
example left is a slightly shortened version by Robin Waistell of
Albatross Boats
|
||||||||||||||||||||||||||||||||||
  |
||||||||||||||||||||||||||||||||||
| Below is a nice example by Geoff Hunt. |  |
|||||||||||||||||||||||||||||||||
 |
 |
|||||||||||||||||||||||||||||||||
| Right and below, an example under construction by Robert Causer. |  |
|||||||||||||||||||||||||||||||||
|
|
 |
|||||||||||||||||||||||||||||||||
|
||||||||||||||||||||||||||||||||||
|
17' ESK SEA KAYAK FULL PLANS COST |
| 19' GREENLAND KAYAK | ||||||||||||||||||||||||||||||||||||
 |
||||||||||||||||||||||||||||||||||||
|
The
Greenland 19 has a simple V bottomed single chine stitch and tape plywood
hull designed to ride out rough water with ease and to have a good turn of
speed. She has an optional daggerboard box to help in directional
stability. The
deck is strip planked over temporary moulds. She has water– tight
compartments fore and aft as well as plenty of storage space. |
||||||||||||||||||||||||||||||||||||
|
||||||||||||||||||||||||||||||||||||
|
19' GREENLAND KAYAK FULL PLANS COST |
| 17' SITON KAYAK | |||||||||||||||||||||||||||||||||
 |
|||||||||||||||||||||||||||||||||
|
This
is a modern ‘sit-on’ type kayak where the cockpits are essentially
open and sealed from the remainder of the kayak. Construction uses 3 or 4mm plywood throughout and the stitch and tape process for the hull. The marked tumblehome in the topsides gives maximum stability for the crew and allows water coming over the deck to shed easily. The
drawings give the position for an alternative single cockpit version and
for a simple rudder system. |
|||||||||||||||||||||||||||||||||
|
|||||||||||||||||||||||||||||||||
|
17' SITON KAYAK FULL PLANS COST |
